Ceramic+Sputter
Magnetron Sputtering Ceramic Technology Breakdown
Core Principles
Magnetron sputtering is a vacuum physical vapor deposition (PVD) technology that bombards ceramic targets (e.g., Titanium Nitride TiN, Indium Tin Oxide ITO) with high-energy ions, depositing nano-ceramic particles uniformly onto polyester substrates to form a multi-layer composite structure.
-
Manufacturing Process:
-
Substrate Cleaning → 2. Vacuum Chamber Pre-Treatment → 3. Magnetron Sputtering Deposition (Multi-Layer Ceramic Coating) → 4. Protective Layer Coating → 5. Precision Laser Cutting
-
- Comparison with Traditional Metal Films:
| Metric | Traditional Metal Film | Magnetron Ceramic Film |
|---|---|---|
| IR Rejection | 85% | 95% |
| Signal Shielding | Blocks GPS/Phone Signals | No Signal Interference |
| Yellowing Resistance (ΔE) | ≤3.0 | ≤1.2 |
Functional Advantages
-
Superior Heat Insulation
-
IR rejection ≥95%, Total Solar Energy Rejection (TSER) 65%-80%, significantly reducing车内温度.
-
Absorbs (rather than reflects) heat, avoiding secondary heat radiation issues of metal films.
-
-
Excellent Optical Performance
-
Light transmittance range: 30%-70% (customizable), haze ≤1.5%, ensuring clear visibility.
-
100% metal-free, no signal interference, compatible with new energy vehicles and smart devices.
-
-
Durability & Eco-Friendliness
-
Temperature resistance: -40℃~150℃ (GB/T 17339 Test), excellent anti-aging performance.
-
Compliant with RoHS/REACH standards, free of heavy metals, environmentally safe.
-
-
Installation-Friendly
-
Thickness: 1.5mil-2mil, elongation ≥500%, bubble-free application on complex curves.
-
Pre-coated release liner design, supports seamless cutting and quick installation.
-
Product Line
|
Item No. |
Visible Light Transmission | Infrared Rejection | IUV Rejection | Thickness |
| CK70 | 66% | 96% | 99% | 2Mil |
| CK35 | 35% | 99% | 99% | 1.5Mil |
| CK20 | 20% | 99% | 99% | 1.5Mil |
| CK15 | 15% | 99% | 99% | 1.5Mil |
| CK10 | 10% | 99% | 99% | 1.5Mil |
B2B Partnership Benefits
-
Technical Advantages
-
Provides lab test reports (TÜV/SGS certified), supporting customer market promotion.
-
Customizable VLT, color, and thickness to meet diverse needs.
-
-
Supply Chain Assurance
-
MOQ 100 rolls, 15-day fast delivery, DAP logistics support worldwide.
-
Offers OEM pre-cut services, compatible with popular models like Tesla and NIO.
-
-
Marketing Support
-
Free product videos, 3D installation demo toolkits.
-
Strategic partners gain dedicated website space and social media exposure.
-
