Magnetron Sputter
Noble Metal Magnetron Sputtering Technology Breakdown
Core Principles
Noble metal magnetron sputtering uses high-purity targets such as gold (Au), silver (Ag), and platinum (Pt) to deposit nano-scale metal particles combined with ceramic oxides (e.g., ITO) onto polyester substrates through vacuum magnetron sputtering, creating a multi-layer structure with high reflectivity and functionality.
-
Manufacturing Process:
-
Substrate Plasma Cleaning → 2. Noble Metal Sputtering (Layer Thickness ≤50nm) → 3. Ceramic Oxide Composite Deposition → 4. Anti-Oxidation Protective Coating → 5. Optical-Grade Quality Inspection & Rolling
-
- Comparison with Traditional Metal Films:
| Metric | Traditional Al/Ti Metal Film | Noble Metal Sputtering Film |
| IR Rejection | 80%-88% | 92%-98% |
| Visible Light Reflectance | 20%-30% | 40%-60% (Customizable Mirror/Matte) |
| Oxidation Resistance (ΔE) | ≤3.0 (2 Years) | ≤0.8 (5-Year Lab Data) |
Functional Advantages
-
Ultimate Heat Insulation & Energy Efficiency
-
IR rejection ≥92%, Total Solar Energy Rejection (TSER) 70%-85%, reducing空调能耗 by 30%-50%.
-
High reflectivity design minimizes heat absorption, ideal for高温 markets like the Middle East and Southeast Asia.
-
-
Full Signal Compatibility
-
Non-continuous noble metal layers + ceramic oxide composite structure ensure zero signal interference (compatible with GPS/5G/ETC).
-
Certified by FCC/CE for electromagnetic compatibility, meeting smart vehicle and IoT device requirements.
-
-
Luxury Aesthetics & Durability
-
Offers premium reflective colors like mirror silver, champagne gold, and rose gold, enhancing vehicle appearance.
-
Exceeds ASTM G154 weathering standards, with ΔE≤1.0 over a 10-year warranty, no fading or peeling.
-
-
Safety & Explosion-Proof Performance
-
Substrate tensile strength ≥45MPa (EN ISO 527-3 Test), bonding glass fragments upon breakage to reduce splash risk.
-
|
Item No. |
Visible Light Transmission | UV Rejection | UV Rejection | Thickness |
| GoldReflect 70 | 70% | 93% | 99% | 3Mil |
| GoldReflect 35 | 35% | 90% | 99% | 2Mil |
| GoldReflect 15 | 25% | 90% | 99% | 2Mil |
B2B Partnership Benefits
-
Technical Customization
-
Precise control of reflectance, color, and VLT (color difference ΔE≤0.5) for brand-exclusive designs.
-
Can integrate transparent conductive layers (surface resistance ≤5Ω/sq) for touchscreen and HUD applications.
-
-
Supply Chain Assurance
-
DAP (Delivered at Place) Logistics: Door-to-door delivery to major global ports, one-stop customs clearance.
-
MOQ 50 rolls, 21-day flexible delivery, supports urgent order prioritization.
-
-
Certifications & Compliance
-
International Certifications: CE, FCC, RoHS, REACH, Saudi SASO, Gulf GCC.
-
Automotive-Grade Test Reports: ISO 105-B06 Lightfastness, ISO 3795 Flammability.
-
-
Marketing Support
-
Free high-resolution product renders and installation case videos.
-
Regional Exclusive Agent Support: Market protection policies and co-branded advertising.
-
